| Product Description: | Double Wire Binding Machine | Speed: | 1200 - 1700 Books Per Hour |
|---|---|---|---|
| Binding Diameter: | 1/4" - 7/8" | Pitch: | 3:1 , 2:1 |
| Operation: | Touch Screen | Feeding Mode: | Semi-Automatic |
| Power: | 220v , 1ph , 50Hz | Net Weight: | 270kg |
| Highlight: | 270kg Wire Binding Machine,50Hz Wire Binding Machine,270kg Wire Spiral Binding Machine |
||
Semi-Automatic Double Wire Binding Machine
Quick Details :
* Semi-automatic binding machine for double wire only , not for single wire ;
* Working speed up to 1200 - 1700 books per hour ;
* Binding diameters can be 1/4" - 7/8" , pitch can be 3:1 or 2:1 ;
* Skip bindings at one time are available , up to 5 skip binding per once
* Touch screen and automatic error reminder ;
* Automatic hanger binding device , automatic books convey device ;
* New slide type pneumatic components extend the machine life and ensure the machine stability .
Specifications :
| Feeding Mode | Semi-Automatic |
| Available Wire Size | 1/4” – 7/8” (pitch 3:1 , 2:1 ) |
| Max Paper Width | 520mm |
| Max Binding Width | 507mm |
| Min Paper Length | 75mm |
| Working Speed | 1200 – 1700 cycle/hour |
| Size Of The Work Table | 660x300mm |
| Power | 220V , 1 ph , 50Hz |
| Air Compressor | 1.5 Kw |
| Air Pressure Bar | 6-8 |
| Machine Dimension | 1000x760x1230mm |
| Net Weight | 270kg |
| Dimensions of Pay-off unit | 490x760x1230mm |
